General information:
Product name: CR 15-5 A-F-A-E-HQQE
Product No: On request
EAN number: On request
Technical:
Pump speed on which pump data are
based: 2917 rpm
Rated flow: 17 m³/h
Rated head: 55.4 m
Maximum head: 70.6 m
Stages: 5
Impellers: 5
Number of reduced-diameter impellers: 0
Low NPSH: N
Pump orientation: Vertical
Shaft seal arrangement: Single
Primary shaft seal: HQQE
Code for shaft seal: HQQE
Approvals: CE,EAC,UKCA,SEPRO,R
CM,
Approvals for drinking water: WRAS,ACS
Curve tolerance: ISO9906:2012 3B
Pump version: A
Model: A
Materials:
Type key, code for materials: A
Type key, code for rubber components.
E = EPDM, V=FKM: E
Base: Cast iron
EN 1561 EN-GJL-200
ASTM A48-25B
Impeller: Stainless steel
EN 1.4301
AISI 304
Material code: A
Code for rubber: E
Bearing: SIC
Installation:
Maximum ambient temperature: 60 °C
Maximum operating pressure: 16 bar
Max pressure at stated temp: 16 bar / 120 °C
16 bar / -20 °C
Type key, code for pipework connection: F
Type of connection: DIN
Size of inlet connection: DN 50
Size of outlet connection: DN 50
Pressure rating for connection: PN 25
Flange size for motor: FT130
Terminal box position: 6
Connect code: F
Liquid:
Pumped liquid: Water
Liquid temperature range:-20 .. 120 °C
Selected liquid temperature: 20 °C
Density: 998.2 kg/m³
Electrical data:
Motor standard: IEC
