General information:
Product name: CR 32-3
A-F-A-E-HQQE
Product No: On request
EAN number: On request
Technical:
Pump speed on which pump data are
based:
2919 rpm
Rated flow: 30 m³/h
Rated head: 44.1 m
Maximum head: 58.5 m
Stages: 3
Impellers: 3
Number of reduced-diameter impellers: 0
Low NPSH: N
Pump orientation: Vertical
Shaft seal arrangement: Single
Primary shaft seal: HQQE
Code for shaft seal: HQQE
Approvals: CE,EAC,UKCA,SEPRO
,
Approvals for drinking water: WRAS,ACS
Curve tolerance: ISO9906:2012 3B
Pump version: A
Model: B
Materials:
Type key, code for materials: A
Type key, code for rubber components. E =
EPDM, V=FKM:
E
Base: Cast iron
EN 1563
EN-GJS-500-7
ASTM A536 80-55-06
Impeller: Stainless steel
EN 1.4301
AISI 304
Material code: A
Code for rubber: E
Bearing: SIC
Support bearing: Graflon
Get the best price and fastest delivery for Grundfos CR32-3 A-F-A-E-HQQE Pump With Motor from Grundfos. Imtek Engineering offers worldwide industrial equipment supply with expert support.
