General information:
Product name: CRN 10-7
A-FGJ-A-E-HQQE
Product No: On request
EAN number: On request
Technical:
Pump speed on which pump data are
based:
2902 rpm
Rated flow: 10 m³/h
Rated head: 57.2 m
Maximum head: 71.7 m
Stages: 7
Impellers: 7
Number of reduced-diameter impellers: 0
Low NPSH: N
Pump orientation: Vertical
Shaft seal arrangement: Single
Primary shaft seal: HQQE
Code for shaft seal: HQQE
Approvals: CE,EAC,UKCA,SEPRO,R
CM,
Approvals for drinking water: WRAS,ACS
Curve tolerance: ISO9906:2012 3B
Pump version: A
Model: A
Materials:
Type key, code for materials: A
Type key, code for rubber components.
E = EPDM, V=FKM:
E
Base: Stainless steel
EN 1.4408
AISI 316
Impeller: Stainless steel
EN 1.4401
AISI 316
Material code: A
Code for rubber: E
Bearing: SIC
