General information:
Product name: CRT 2-7
A-P-A-V-AUUV
Product No: On request
EAN number: On request
Technical:
Pump speed on which pump data are
based: 2900 rpm
Rated flow: 2.5 m³/h
Rated head: 40 m
Maximum head: 65.1 m
Stages: 7
Impellers: 7
Primary shaft seal: AUUV
Code for shaft seal: AUUV
Approvals: CE,EAC,UKCA,SEPRO
Curve tolerance: ISO9906:2012 3B
Pump version: A
Model: A
Materials:
Type key, code for materials: A
Type key, code for rubber components. E =
EPDM, V=FKM: V
Pump housing: Titanium
Impeller: Titanium
ASTM B 265
ASTM B265
Material code: A
Code for rubber: V
Bearing: SIC
Installation:
Maximum operating pressure: 25 bar
Max pressure at stated temp: 25 bar / 90 °C
25 bar / -20 °C
Type key, code for pipework connection: P
Type of connection: PJE
Pipe connection: 42,4 mm
Flange size for motor: FT100
Connect code: P
Liquid:
Pumped liquid: Water
Liquid temperature range:-20 .. 90 °C
Selected liquid temperature: 20 °C
Density: 998.2 kg/m³
Electrical data:
Motor standard: IEC
Power (P2) required by pump: 0.75 kW
Controls:
Frequency converter: None
Others:
Minimum efficiency index, MEI ≥: 0.7
Net weight: 10.2 kg
Gross weight: 15.2 kg
Shipping volume: 0 m³
