General information:
Product name: DDC 15-4
A-PVC/V/C-F-31I002FG
Product No: On request
EAN number: On request
Technical:
Type key: DDC 15-4
A-PVC/V/C-F-31I002FG
Max. Flow: 15 l/h
Max. flow in slow mode 50%: 7.5 l/h
Max. flow in slow mode 25%: 3.75 l/h
Min flow: 15.0 ml/h
Turn-down ratio: 1:1000
Approvals: CE,CSA-US,NSF61,EAC,RCM
Valve type: Standard
Maximum viscosity at 100 %: 300 mPas
Maximum viscosity in slow mode 50
%:
1300 mPas
Maximum viscosity in slow mode 25
%:
2000 mPas
Accuracy of repeatability: 1 %
Materials:
Dosing head: PVC (Polyvinyl chloride)
Valve ball: Ceramic
Gasket: FKM
Installation:
Range of ambient temperature: 0 .. 45 °C
Maximum operating pressure: 4 bar
Installation set (Yes/No): YES
Installation type: 9/12 mm up to 60 l/h,13 bar
Pump inlet: Hose 9/12 mm 6
Pump outlet: Hose 9/12 mm 6
Max. Suction lift during operation: 6 m
Max. Suction lift during priming: 3 m
Liquid:
Pumped liquid: Water
Liquid temperature range: 0 .. 45 °C
Selected liquid temperature: 20 °C
Density: 998.2 kg/m³
