General information:
Product name: DMH 2,4-10
B-SS/T/SS-X-41AAXE5AG
Product No: On request
EAN number: On request
Technical:
Nominal flow rate at 50 Hz: 2.4 l/h
Number of dosing heads: 1
Approvals: CE,ATEX,EAC,CNROHSEX
Non return valve type, inlet pump
1: Standard
Non return valve type, outlet
pump 1: Standard
Max viscosity: 300 mPas
Materials:
Pump housing: Aluminium
Dosing head, pump 1: Stainless steel
EN 1.4571
Valve ball: Stainless steel
Valve ball: EN 1.4401
Valve seat: Composite
Valve seat: PTFE
Valve gasket: PTFE
Valve gasket: Composite
Installation:
Max operating pressure at 50 Hz: 10 bar
Maximum permissible inlet
pressure: 8 bar
Type of inlet connection: Rp
Type of outlet connection: Rp
Size of inlet connection: 1/4 inch
Size of outlet connection: 1/4 inch
Liquid:
Pumped liquid: Water
Liquid temperature range:-10 .. 90 °C
Selected liquid temperature: 20 °C
Density: 998.2 kg/m³
Electrical data:
Power input P1: 0.2 kW
Mains frequency: 50 Hz
Max. frequency: 100 Hz
Rated voltage: 3 x 230/400 V
Enclosure class (IEC 34-5): IP65
Cable included (Yes/No): N
Power plug: No plug
Controls:
Type of connector: No plug
Type of control variant: Standard
Frequency converter: Prepared for VFD
Others:
Net weight: 14 kg
Gross weight: 25.3 kg
Shipping volume: 0.156 m³
Diaphragm Leakage Detection: N
