General information:
Product name: NBE 100-200/219
AAF2KESBQQEVW1
Product No: On request
EAN number: On request
Technical:
Pump speed on which pump data
are based:
3000 rpm
Rated flow: 321.7 m³/h
Rated head: 58.11 m
Actual impeller diameter: 219 mm
Nominal impeller diameter: 200
Shaft seal arrangement: Single
Primary shaft seal: BQQE
Shaft diameter: 32 mm
Code for shaft seal: BQQE
Curve tolerance: ISO9906:2012 3B
Pump version: A
Bearing design: Standard
Materials:
Type key, code for materials: K
Type key, code for rubber
components. E = EPDM, V=FKM:
E
Pump housing: Stainless steel
EN 1.4408
ASTM CF8M
Wear ring: Stainless steel
EN 1.4517
ASTM CD4MCuN
Flange: Cast iron
EN-GJS-500-7
ASTM 70-50-05
Impeller: Stainless steel
EN 1.4408
ASTM CF8M
Pump house, internal coating: No coating
Material code: K
Code for rubber: E
Shaft: Stainless steel
EN 1.4401
AISI 316
Installation:
Range of ambient temperature: -10 .. 50 °C
Maximum operating pressure: 16 bar
Type key, code for pipework
connection:
F2
Pipe connection standard: EN 1092-1
Size of inlet connection: DN 125
Size of outlet connection: DN 100
Pressure rating for connection: PN 16
Bearing lubrication: Grease
Pump housing with feet (Yes/No): Yes
Support block (Yes/No): N
Connect code: F2
Liquid:
Pumped liquid: Water
Liquid temperature range: -25 .. 120 °C
Selected liquid temperature: 20 °C
