General information:
Product name: TP 40-190/2
A-F-A-BQBE-FW1
Product No: On request
EAN number: On request
Technical:
Pump speed on which pump data are
based: 2889 rpm
Rated flow: 10.8 m³/h
Rated head: 13.3 m
Maximum head: 190 dm
Actual impeller diameter: 124 mm
Primary shaft seal: BQBE
Code for shaft seal: BQBE
Curve tolerance: ISO9906:2012 3B2
Pump version: A
Materials:
Type key, code for materials: A
Pump housing: Cast iron
EN-GJL-250
ASTM class 35
Impeller: Stainless steel
EN 1.4301
AISI 304
Material code: A
Installation:
Range of ambient temperature:-30 .. 60 °C
Maximum operating pressure: 16 bar
Max pressure at stated temp: 16 bar / 140 °C
Type key, code for pipework connection: F
Pipe connection standard: EN 1092-2
Type of connection: DIN
Size of connection: DN 40
Pressure rating for connection: PN 16
Port-to-port length: 320 mm
Flange size for motor: FT100
Connect code: F
Liquid:
Pumped liquid: Water
Liquid temperature range: 0 .. 140 °C
Selected liquid temperature: 20 °C
Density: 998.2 kg/m³
Electrical data:
Motor type: 80A
Rated power - P2: 0.75 kW
Mains frequency: 50 Hz
Rated voltage: 3 x 220-240D/380-415Y V
Rated current: 3.30/1.90 A
Starting current: 580-620 %
Cos phi - power factor: 0.81-0.71
Rated speed: 2840-2870 rpm
IE Efficiency class: IE3
Motor efficiency at full load: 80.7 %
Motor efficiency at 3/4 load: 82.7-80.9 %
Motor efficiency at 1/2 load: 81.7-77.9 %
Number of poles: 2
