General information:
Product name: Unilift CC9 - A1
Product No: On request
EAN number: On request
Technical:
Rated flow: 1.88 l/s
Maximum flow: 3.89 l/s
Rated head: 6.56 m
Maximum head: 9 m
Max. Particle: 10 mm
Approvals: CE,LGA,VDE,UKCA,SEPRO
Materials:
Pump housing: Polypropylene
PP - GF15
Impeller: Composite
PP 20 GF
Motor: Stainless steel
EN 1.4301
AISI 304
Shaft: Stainless steel
EN 1.4301
AISI 304
Strainer: Stainless steel
EN 1.4301
AISI 304
Installation:
Range of ambient temperature: 0 .. 40 °C
Type of connection: R
Size of connection: 1 1/4 inch
Maximum installation depth: 7 m
Liquid:
Liquid temperature range: 0 .. 40 °C
Selected liquid temperature: 20 °C
Density: 998.2 kg/m³
Electrical data:
Power input P1: 780 W
Rated power - P2: 0.465 kW
Mains frequency: 50 Hz
Rated voltage: 1 x 220-240 V
Rated current: 3.5 A
Rated speed: 2850 rpm
Capacitor size - run: 8 µF/450 V
Enclosure class (IEC 34-5): IP68
Insulation class (IEC 85): B
Ex-protection standard: YES
Length of power cable: 10 m
Type of cable plug: SCHUKO
Controls:
Level switch: A
Others:
Net weight: 6.79 kg
Gross weight: 7.55 kg
Shipping volume: 0.017 m³
Danish VVS No.: 391280391
Swedish RSK No.: 5885926
Norwegian NRF no.: 9045642
Country of origin: HU
