Mts Sensor EP-O-0600M-D34-1-A01

Mts Sensor

Product Code: EP-O-0600M-D34-1-A01
Brand: Mts Sensor



GET OFFER: info@imtek.com.tr

Description for Mts Sensor EP-O-0600M-D34-1-A01

InputMeasured variable PositionStroke length 50 - 2500 mmOutputInterface CAN System ISO-DIS 11898Data protocol CANopen: CIA Standard DS 301 V3.0 / Encoder Profile DS 406 V3.1Baud rate, kBit/s 1000 800 500 250 125Cable length, m < 25 < 50 < 100 < 250 < 500The sensor will be supplied with ordered baud rate, which is changeable by customerAccuracyResolution 10 µm, 20 µmVelocity 1 mm / sLinearity, deviation < ± 0.02 % F.S. (Minimum ± 60 µm)Repeatability < ± 0.005 % F.S. (Minimum ± 10 µm)Temperature coefficient < 15 ppm/ºCUpdate frequency 1 msOperating ConditionsMagnet speed AnyOperating temperature -40° C ... +75° CDew point, humidity 90 % rel. humidity, no condensationIngress protection IP67 with proper mating connectorShock test 100 g (single shock) IEC-Standard 60068-2-27Vibration test 15 g / 10 - 2000 Hz IEC-Standard 60068-2-6 (resonance frequencies excluded)EMC-Test Electromagnetic emission EN 61000-6-4 (for use in industrial environment)Electromagnetic immunity EN 61000-6-2The sensor meets the requirements of the EC directives and is marked with CEDesign / MaterialSensor enclosure AluminumSensor housing AluminumPosition magnet type Magnet slider hard ferrite, block magnet plasticInstallationMounting type Adjustable mounting clampsElectrical connectionConnection type 5 pin connector M12Supply voltage 24 VDC (+20 % / -15 %)Current consumption max. 90 mARipple < 0.288 VppDielectric strength 500 VDC (DC ground to machine ground)Polarity protection > -30 VDCOvervoltage protection < 36 VDC
