EKF S20-NVME Low Profile Mezzanine for Compact PCI Serial CPU Cards

EKF

Product Code: EKF S20-NVME Low Profile Mezzanine for Compact PCI Serial CPU Cards
Artikelnummer: S20-NVME
Brand: EKF



GET OFFER: info@imtek.com.tr

Description for EKF S20-NVME Low Profile Mezzanine for Compact PCI Serial CPU Cards

Form FactorProprietary size mezzanine module 84.3mm x 95mmFits basically into the 4HP (20.3mm) envelope of the CPU carrier boardTypically delivered as a ready to use assembly unit (including SC4-CONCERTO or successor CPU card)Mounting position right (on top of a CPU board or CPU side card)Host I/F Connectors HSE1High speed mezzanine connectorsSuitable for PCI Express® Gen3, USB 3.0 SuperSpeedBottom mount male connector HSE1 (high speed expansion)Mating with the carrier card female connector HSE1Board-to-board height 10.0mm for a 4HP assemblyCutout around carrier card connector HSE2 - allows additional side card use (8HP front panel width in total)PCI Express® x4 support, dedicated to the NVMe SSD module M.2 socket1 x USB 3.1 Gen1 5Gbps support, dedicated to the Type-C USB front panel I/O connector)Power sourcing 12V/1.5 A maximum continuous current (2 pins)M.2 Module ConnectorM.2 socket key Id M, for 1 x NVMe (PCIe x4) SSD, M.2 size up to 2280Power switch for M.2 module undervoltage lockout, short-circuit protection, quick dischargeM.2 NVME SSD module socket, key Id M, PCIe x4 I/FPCIe x4 sourced via HSE1 mezzanine connectorMaximum (theoretical) 32Gbps I/O data transfer rate (Gen3 PCIe 8GT/s)Type-C Front Panel ConnectorType-C front panel receptacleSuitable for Type-C compliant USB cable assembliesSupport for Type-C locking plugs (dual screw) according to the 'Locking Connector Spec. Rev. 1.0'VBUS over voltage, surge, and ESD protectionHost mode USB 3.1 Gen 1 (5Gbps SuperSpeed), passed through from HSE1 mezzanine connector (CPU carrier card USB host controller e.g. PCH)Downstream Facing Port (DFP) controller and power switch, up to 5V/3A VBUS10Gbps MUX for Type-C flip control (signal flow according to the cable plug orientation)USB 3.1 Gen 2 ready (10Gbps SuperSpeed+) for future CPU chipset generationApplicationsLow profile mezzanine module for EKF CPU Cards (SC4-CONCERTO, SC5-FESTIVAL and successional)4HP assembly CPU carrier board and S20-NVME mezzanine cardM.2 based mass storage, M.2 PCIe x4 socket (NVMe)Optional front panel I/O (2 x Type-C, dual screw locking)Front panel I/O connector Type-C, dual screw locking, USB 3.1 Gen 1Environmental & RegulatoryDesigned & manufactured in GermanyISO 9001 certified quality managementLong term availabilityRugged solutionCoating, sealing, underfilling on requestLifetime application supportRoHS compliantOperating temperature 0°C to +70°COperating temperature -40°C to +85°C (industrial temperature range) on requestStorage temperature -40°C to +85°C, max. gradient 5°C/minHumidity 5% ... 95% RH non condensingAltitude -300m ... +3000mShock 15g 0.33ms, 6g 6msVibration 1g 5-2000HzMTBF 141.8 yearsEC Regulatory EN55022, EN55024, EN60950-1 (UL60950-1/IEC60950-1)
