General information:
Product name: CM 10-2 A-R-A-E-AVBE
F-A-A-N
Product No: On request
EAN number: On request
Technical:
Pump speed on which pump data are
based: 2900 rpm
Rated flow: 10 m³/h
Rated head: 27.09 m
Impellers: 2
Primary shaft seal: AVBE
Code for shaft seal: AVBE
Approvals: CE,EAC,UKCA
Approvals for drinking water: ACS,NSF61
Curve tolerance: ISO9906:2012 3B
Pump version: A
Model: A
Materials:
Type key, code for materials: A
Type key, code for rubber components.
E = EPDM, V=FKM: E
Pump housing: Cast iron
EN-GJL-200
ASTM A48-25A
Impeller: Stainless steel
EN 1.4301
AISI 304
Material code: A
Code for rubber: E
Installation:
Range of ambient temperature:-20 .. 55 °C
Maximum operating pressure: 10 bar
Max pressure at stated temp: 10 bar / 40 °C
6 bar / 90 °C
Type key, code for pipework
connection: R
Type of connection: Rp
Size of inlet connection: 1 1/2 inch
Size of outlet connection: 1 1/2 inch
Terminal box position: 12
Outlet position: 12
Connect code: R
Liquid:
Pumped liquid: Water
Liquid temperature range:-20 .. 90 °C
Selected liquid temperature: 20 °C
Density: 998.2 kg/m³
Electrical data:
Motor standard: IEC
Frame size: 90SD
IE efficiency class: IE3
Rated power - P2: 1.5 kW
Mains frequency: 50 Hz
Suitable for 50/60 Hz (Yes/No): N
Rated voltage: 3 x 220-240D/380-415Y V
Service factor: 1.00
Rated current: 5.70/3.30 A
